Lantronix’s Open-Q™ 2100 System on Module (SOM) is an ultra-compact production and wearable ready Snapdragon™ Wear 2100 SOM. Our SOM is 15mm x 31.5mm—half the size of a postage stamp.

The 2100 SOM’s ultra-compact size (15mm x 31.5mm), advanced technology, and extensive range of peripherals provide the perfect platform for creating high performance, miniature embedded or wearable products. Use our class leading wearable SOM to fast track your ultra-compact embedded or wearable product development.

Open-Q™ 2100 SOM (System on Module) Discontinued

Related Products

Open-Q™ 2100 SOM (System on Module) Overview

Lantronix’s Open-Q™ 2100 System on Module (SOM) is an ultra-compact production and wearable ready Snapdragon™ Wear 2100 SOM. Our SOM is 15mm x 31.5mm—half the size of a postage stamp.

The 2100 SOM’s ultra-compact size (15mm x 31.5mm), advanced technology, and extensive range of peripherals provide the perfect platform for creating high performance, miniature embedded or wearable products. Use our class leading wearable SOM to fast track your ultra-compact embedded or wearable product development.

Open-Q™ 2100 SOM (System on Module) Tech Specs

    Processor

    • Snapdragon™ Wear 2100 optimized for wearables
      • Quad-Core ARM Cortex A7 at 1.094GHz
      • Qualcomm® Adreno 304 GPU

    Other Interfaces

    • USB 2.0
    • I2S
    • GPIO
    • MIPI
    • SDC2/microSD

    Memory/Storage

    • 512MB RAM
    • 4GB Flash

    Location

    • Gen 8C GNSS with onboard U.FL connector

    Audio

    • Integrated Codec/PMIC
    • Fluence™ HD with Noise Cancellation
    • Snapdragon™ Voice Activation
    • Snapdragon™ Voice+

    Wireless

    • Wi-Fi 802.11b/g/n 2.4 GHz single band
    • Bluetooth 4.2, Bluetooth Low Energy

    Display

    • Up to 720p at 60fps optimized for wearables

    Operating Environment

    • Input 3.6V to 4.2V
    • Operating Temperature: -25°C to +85°C Tc (component case temperature)
    • 2x 100 pin board to board connectors
    • 31.5mm x 15mm

    Camera

    • 2-lane MIPI CSI support up to 8MP

    OS Support

    • Android 7 Customized for Wearable products

    Specifications are subject to change without notice. Not all features listed may be supported in software. All brand or product names are trademarks or registered trademarks of their respective owners. Qualcomm Snapdragon, Qualcomm Kryo, Qualcomm Spectra, Qualcomm Adreno, Fluence and Qualcomm Hexagon are products of Qualcomm Technologies, Inc. Qualcomm IZat is a product of Qualcomm Atheros, Inc. Qualcomm, Snapdragon, Adreno, Fluence and Hexagon are trademarks of Qualcomm Incorporated, registered in the United States and other countries. Kryo, Spectra and IZat are trademarks of Qualcomm Incorporated. Used with permission.

    Lantronix and Open-Q and their respective logos are trademarks, registered and otherwise, of Lantronix Technologies Corporation in Canada, European Union, Taiwan, United States of America and other jurisdictions.

Open-Q™ 2100 SOM (System on Module) Resources

Application Spotlights
Videos
Press Releases
    string(0) "" string(0) "" NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL string(0) "" NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL string(0) "" NULL NULL NULL NULL NULL string(0) "" NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL NULL
Case Studies

Open-Q™ 2100 SOM (System on Module) Downloads

Document Size
Open-Q 2100 SOM Product Brief 705 KB

Open-Q™ 2100 SOM (System on Module) Part Numbers

Click on a cart button below to buy direct from Lantronix.



QC-DB-J00004 Open-Q™ 2100 System on Module

SOM Only
QC-DB-J00003 Open-Q™ 2100 Development Kit

Companion Development Kit
Lantronix Part # Name Description Order Now
