Lantronix E210 Series Routers

E210 Series

With high-speed  LTE, WAN, LAN, Wi-Fi and serial connectivity, Lantronix E210 is designed for mission-critical enterprise applications requiring faultless connectivity.

Product Highlights

  • 3G and LTE Cellular / wired WAN / LAN / Wi-Fi
  • RS-232 operation
  • 8 V dc ~ 32 V dc power input
  • Advanced failover and load balancing
  • Access point mode with multiple SSIDs
  • Multiple tunnelling scheme
  • GPS output and SMS event reporting
  • User-friendly GUI
  • OTA configuration management

E210 Series

    Overview for E210 Series

     Main Markets



    e210 - electric vehicle charging station e210 - vending machine e210 - security & surveillance e210 - digital signance e210 - POS payment system e210 - ATM e210 - Kiosk



    With high-speed LTE, Cat1, WAN, LAN, Wi-Fi and serial connectivity, Lantronix E210 is designed for M2M and enterprise IoT applications, including industrial automatisation, point-of-sale payments, infrastucture and transportation with a robust connectivity requiring faultless connectivity. It provides state-of-the-art load balancing, multiple VPN tunneling schemes including IPsec, cellular / WAN / Wi-Fi failover scheme. It has an automatic failover functionality to ensure Internet connectivity for your applications with minimum connection problems. With dual SIM support, the router can use your own script to selectively choose the SIM used for data, or to easily switch between them based on Quality of Service (QoS).

    Dual SIM single standby (“DSSS”) operation

    Lantronix E210 has an automatic failover functionality that avoids you to lose communication anytime you have a connection problem. Cellular redundancy by dual SIM support. Switching based on Quality of Service. Program your own scripts and conditions of switching

    e210 - dual sim

    OTA Updates

    Lantronix E210 offers lots of features in order to let you have the most useful experience possible. Maestro gives you a clean, neat and intuitive interface to configure your router in matter of second. You can also do software upgrades Over the Air (OTA): a very convenient way to operate when you have many routers at different locations

    e220 - OTA updates

    Real time analysis

    Our interface let you analyze your CPU load, the traffic on every single interface linked to the router and their connection details. This tool allows you to check your connection parameters in real time.

    e220 - real time analysis

    VPN

    Open VPN offers highest performance and is reliable on high latency connections and is easy to set up. With a 256-bit encryption protocol, your informations are safe. This platform offers improved stability and a great compatibility for all your devices.

    e220 - vpn

    Load balancing

    As a versatile and multi-connected device, Lantronix E210 let you set up the load you want for every single device connected to your router. If a crucial component for your business needs more bandwidth than the others in order to work properly, you can allocate more resources to this specific component in a matter of seconds.

    e220 - load balancing

    SD card supported

    64GB HDHC cards support. Store logs for records, store external device data for data logging purposes

    e210 - sd card

    Snap Cap

    Snappily converts E210 Series’ RS232 port into an isolated, half- or full-duplex, RS-485 port

    e210 - snapcap

      Features & Specifications for E210 Series



      FEATURES E215#02 E213 E214#02
      Processor speed 580Mhz 580Mhz 580Mhz
      Operating System OpenWrt OpenWrt OpenWrt
      RAM 128MB 128MB 128MB
      Flash 32MB 32MB 32MB
      SD Card SD HC ExFAT SD HC ExFAT SD HC ExFAT
      Last Gasp (>10ºC) No No No
      RS232 Yes Yes Yes
      RS485 OPT OPT OPT
      Input/Output 2 DI / 2 DO 2 DI / 2 DO 2 DI / 2 DO
      RTC 100 days 100 days 100 days
      Temp Range -20 to +60 -20 to +60 -20 to +60
      DC Input 8-32VDC 8-32VDC 8-32VDC
      GSM Engine HL8518 WP7702 WP7607-1
      Cellular HSPA LTE-M1/NB-Iot LTE Cat 1
      4G Bands NA 1/2/3/4/5/8/12/13/17/18/19/20/26/28 1/3/7/8/20/2
      3G Bands 1/8 NA 1/8
      EVDO NA NA NA
      2G Bands 3/8 2/3/5/8 3/8
      CDMA NA NA NA
      Downlink 7.2 Mbps Cat-M1: 300kbps
      Cat-NB1: 27kbps
      10Mbps
      Uplink 5.76Mbps Cat-M1: 375kbps
      at-NB1: 65kbps
      5Mbps
      SIM Slots 2 2 2
      WiFi 1T1R 1T1R 1T1R
      WiFi Max Users 25 25 25
      GPS OPT OPT OPT
        HARDWARE
      Material Brushed aluminium alloy
      Dimensions (mm) 92.5 x 57.2 x 22.5 without connectors
      Weight (g) Approx. 150
      Temperature & humidity ranges *Operating*: -20 °C ~ +60 °C; up to 95% RH

      – Storage: -40 °C ~ +85 °C; up to 95% RH

      CPU – MIPS32â 24KEcä CPU running at 580 MHz

      – Built-in 64 KB [resp. 32 KB] instruction [resp. data] cache

      SPI Flash memory 32 MB
      *DDR2 SDRAM* 128 MB
      Power-off
      timekeeping
      RTC with an approx. 100-day data retention period; courtesy of a 15 mWh lithium manganese battery (not functional below -20 °C)
      Power
      consumption (W)
      All figures worst-case (60 °C, 32 V, all subsystems fired on, etc.)

      – Idle:                              0.96 (E215); 1.10 (E214); 1.10 (E218)

      – Standby:                         2.31 (E215); 2.63 (E214); 2.63 (E218)

      – Communication (Tx max.):  5.54 (E215); 6.18 (E214); 6.18 (E218)


        ePack SOFTWARE SUITE
      Administration
      and Network
      protocols
      Web-based user interface, setup wizard, console log viewer, save / load configuration, NTP, SMS / OTA remote configuration, TR-069-capable
      Redundancy Ethernet, Cellular, Wi-Fi – configurable as failover or load balancing
      Resilience Network connectivity watchdog (configurable), internal application watchdog
      Wi-Fi Client or Access point (approx. 40-user), multiple SSID, WEP, WPA, WPA-PSK / WPA2-PSK security modes
      Device management services via either our own D2Sphereä platform or third-party platforms such as TrinitySMART, Thingworx, Thing+, Cumulocity, etc.
      Security Zone-based firewall, VLAN, DMZ, HTTPS local and remote
      connection, SIM PIN
      Performance and Fault management Real time processor load and interface (WAN / LAN / Wi-Fi), traffic analysis, ICMP, trace-route, NS lookup
      Routing DHCP, static routing, port forwarding, traffic routing, static /
      dynamic DNS, DNS proxy, NAT, STP
      VPN PPTP client, L2TP, OpenVPN client / server / passthrough, GRE,
      IPsec
      Industrial
      protocols
      Modbus RTU to TCP support; Modbus master

        OPERATION and CONTROLS
      Power 8 V dc ~ 32 V dc with Slow Start; via the upper row of a dual row,
      4-pin, Micro-Fit™ 3.0 header
      I/Os Two isolated digital I/Os; via the lower row of the same header

      – Input: 0 V dc ~ 1 V dc à zero; 1.4 V ~ 36 V dc à one

      – Output: open collector; 100 mA max.; 36 V dc max.

      Reset button Short (2 s £ < 10 s) / Long (³ 10 s) press for Soft / Hard Reset
      RS-232 Full implementation; via a 9-pin sub-D header
      10/100BASE-T
      Ethernet
      One LAN port and one WAN port, user-reconfigurable as second LAN
      port; via RJ-45 headers fitted with two LEDs
      Wi-Fi 1T1R Wi-Fi 4; via an RP-SMA antenna connector
      Cellular
      (details in the
      table below)
      One- or two-antenna models as:

      – 3G E215[G]; LTE-M1 E213G; via an SMA antenna connector

      – LTE cat. 1 E214[G]; LTE cat. 4 E218[G]; via two SMA antenna connectors (main and diversity)

      *Dual SIM* Dual SIM / Single standby (“DSSS”); via two mini-SIM held in trays
      *Location
      services
      *
      Concurrent GPS and GLONASS (E215G, E213G); IZat™ gen. 8C
      gpsOne (E214G, E218G); via a dedicated SMA antenna connector
      *Data storage* via a user-accessible microSD card (not provided)
      Operating
      status LEDs
      Seven as green for (i) Power; blue for (ii) SIM; (iii) Wi-Fi; amber for
      (iv) Activity; (v) Network; (vi) Signal; red for (vii) Alert

        *FACTORY OPTIONS* (subject to MOQ and other considerations)
      “XTR” -30 °C ~ +70 °C operating temperature range
      DDR2 SDRAM Doubled to 256 MB
      Alternate
      data storage
      64 MB [resp. 1 GB] of internal Flash memory, arranged in 512- [resp.
      2,048-] byte pages, substituted for the standard microSD card holder
      MFF SIM(s) Combination of (i) ‘MFF + mini’; or (ii) ‘mini + MFF’; or (iii) ‘MFF + MFF’ SIMs, substituted for the standard two mini-SIM trays
      Location
      services
      IZat™ gen. 8C gpsOne (E214#02, E214#078, E218#04 only); via a
      dedicated SMA antenna connector

        ADD-ON
      Snap Capä SC485, a 9-pin male sub-D plug that ‘snappily’ converts any E210 unit into an isolated, half- or full-duplex (user-selectable via a slide switch) RS-485 unit via a 5-pin, 3.5 mm pitch, COMBICON header

        ESSENTIAL ACCESSORIES
      Power cords KDC42 or KDC44 (the latter with two more stripped wires for I/Os)
      Remote, adhesive,
      cellular and
      cellular / GNSS
      antennas
      All IP67-rated, except for A31M0 (IP33) and A31H0 (N/A)

      – A31M0 or A31H0, LTE: E215

      – A14M0 or A14H0, ‘2-in-1’ LTE + GNSS: E215G, E213G

      – A32M0 or A32H0, ‘2-in-1’ LTE + LTE: E214, E218

      – A33M0 or A33H0, ‘3-in-1’ LTE + LTE + GNSS: E214G, E218G

      Wi-Fi antennas L-shaped, hinged, A24C0 (while stocks last) or A21H0
      DIN Rail clip BR551, dual mount 5½ U or 1½ U; mounting bracket too

    Order Information & Part Numbers for E210 Series

    ROUTERS
    E214F002S E214#02 E210 Standard

    Router E214 EMEA Malaysia - LTE cat. 1 band 28, 20, 8, 3, 1, 7 - 3G FB 8,1 - 2G FB band 8, 3 - 2 Ethernet, Dual SIM, RS-232 port, Wi-Fi, SD card, 2 I/O - Epack

    Contact Us
    E214F00CS E214#078 E210 Custom

    Router E214 China, Indonesia, India - LTE cat. 1 band 5, 8, 3, 1; TDD 40, 41 - 3G FB 8,1 - 2G FB band 8, 3 - 2 Ethernet, Dual SIM, RS-232 port, Wi-Fi, SD card, 2 I/O - Epack

    Contact Us
    E214F003S E214#358S#158 E210 Standard

    Router E214 ANZ Thailand - LTE Cat 1 band 28/5/8/3 - 3G FB 5, 8,1 - 2 Ethernet, Dual SIM, RS-232 port, Wi-Fi, SD card, 2 I/O - Epack

    Contact Us
    E214G000S E214G#00 E210 Standard

    Router E214 AT&T, T-Mobile - LTE cat. 1 band 12, 5, 4, 2 - 3G FB 5, 4, 2 - 2 Ethernet, Dual SIM, RS-232 port, Wi-Fi, SD card, 2 I/O - Epack

    Contact Us
    E214G001S E214G#01 E210 Standard

    Router E214 Verizon - LTE cat. 1 band 13, 14 - 2 Ethernet, Dual SIM, RS-232 port, Wi-Fi, SD card, 2 I/O - Epack

    Contact Us
    E215F002S E215#02 E210 Standard

    Router E215 EMEA Asia - 3G band 8, 1 - 2GFB band 8, 3- 2 Ethernet, Dual SIM, RS-232 port, Wi-Fi, SD card, 2 I/O - Epack

    Contact Us
    E218F004S E218#04 E210 Custom

    Router E218 Brazil ANZ Thailand Malaysia Singapore - LTE Cat4 band 28, 5, 8, 3,1 - 3G FB 5, 8, 1 2G FB 8, 3 - 2 Ethernet, Dual SIM, RS-232 port, Wi-Fi, SD card, 2 I/O - Epack

    Contact Us
    E218F009S E218#1357 E210 Custom

    Router E218 LG U+ - LTE Cat4 band 5, 3, 1, 7 - 2 Ethernet, Dual SIM, RS-232 port, Wi-Fi, SD card, 2 I/O - Epack

    Contact Us
    E218F006S E218#1BI E210 Custom

    Router E218 KDDI - JAPAN - LTE Cat4 band 18, 11, 1 - 2 Ethernet, Dual SIM, RS-232 port, Wi-Fi, SD card, 2 I/O - Epack

    Contact Us
    E218F005S E218#1JL E210 Custom

    Router E218 DoCoMo - JAPAN - LTE Cat4 band 19, 21, 1 - 2 Ethernet, Dual SIM, RS-232 port, Wi-Fi, SD card, 2 I/O - Epack

    Contact Us
    ACCESSORIES
    MF13 E214, E218 accessory bundle Accessories Bundle

    E214, E218 accessory bundle : Power cord KDC44, Antenna A32M0 & A21HO, Din rail clip BR551

    Contact Us
    MF14 E214G, E218G accessory bundle Accessories Bundle

    E214G, E218G accessory bundle : Power cord KDC44, Antenna A33M0 & A21HO, Din rail clip BR551

    Contact Us
