XPort EDGE
Focus

Embedded Wired Ethernet IoT Gateway Integrated with Percepxion

The Next Generation Wired Ethernet Gateway and Device Server in the same compact form factor as the Lantronix XPort. Integrated with Lantronix’s Percepxion™ cloud-based IoT edge solution platform.

XPort® EDGE is a network communications engine for secure IoT connectivity and remote management that fits within a standard Ethernet connector. Requiring minimal engineering effort, the XPort EDGE allows device manufacturers to add fully integrated, secure Ethernet connectivity and control to their products in a few weeks.

Key Features
  • Integrated with Percepxionâ„¢ IoT Edge solution platform
  • Network & IoT Offload
  • Full IoT Gateway Functionality in a single RJ45 package
  • Industrial-grade Security
  • Robust Data Handling
  • Integrated Device Manageability
  • Cloud Ready
  • Faster Time to Market
  • Lower TCO
  • Quickest Integration
NDAA Compliant

XPort EDGE Overview

Product Highlights:

  • Customer-proven Serial-to-Ethernet technology (TruPort® Serial and TruPort® Socket) for secure data communication
  • Secure Boot, Secure Firmware Updates
  • Built-in Infinishieldâ„¢ Security for Data-at-Rest and Data-in-Motion Security
  • Pre-Integration with Percepxionâ„¢ Software Platform for Remote Management and Application Integration
  • SSL/TLS 1.2 with PKI and X.509 Certificate Management
  • Secure Network Attach (EAPOL)
  • Integrated RJ45 Ethernet Jack Magnetics, 10/100 Mbps PHY, Industrial Operating Temperature Range (-40°C to + 85°C)”

Advanced Security Features

Leverage a comprehensive suite of built-in device security software with minimal integration effort. Lantronix Infinishieldâ„¢ Security offers instant access to key features such as secure boot, secure firmware updates, secure connections, data-at-rest protection for keys and configuration and role-based access control.

Robust Data Connectivity

Reliably and securely communicate your device data with one or more applications on the local network or across the Internet. Utilize customer proven TruPort® Serial for transparent pass-through of hundreds of serial protocols or TruPort® Socket for multiple connections via TCP, UDP and HTTP(S) Server.

Comprehensive Device Security Framework

XPort Edge includes a comprehensive suite of built-in device security applications that offer robust and secure connections, data-at-rest protection for keys, configuration, secure boot and secure firmware-over-the-air (FOTA) updates, user role-based access control and fine-grained policy-based network service control.

Remote Management & Cloud Connectivity

Centralized device management and data access to your devices via Lantronix Percepxionâ„¢ cloud platform.

Fastest Device Integration

Everything you need is included in the tiny RJ45 Ethernet connector package. Connect to any 8/16/32-bit microcontroller with a UART interface. Simplify your device application with fully offloaded network stack, robust security, connectivity, and management software.

Case Studies

printing machine
Manufacturing & Agriculture
Enable the addition of network connectivity to Link-Tech’s next-generation printing using the Lantronix XPort to provide real-time monitoring and maintenance for a more accurate solution.
industrial automation
Manufacturing & Agriculture
Reduce development costs and engineering resources by adding Lantronix network connectivity to keep the product development cycle on the fast track.
smart motor
Manufacturing & Agriculture
Offer a compact, easy-to-integrate, complete network connection using the Lantronix XPort to accelerate time-to-market for SmartMotors.
traffic light
Manufacturing & Agriculture
Propose a cost-effective approach using the Lantronix XPort to create a wireless Ethernet backbone to allow traffic controllers to communicate securely over the internet.
security camera
Security & Video Surveillance
Offer serial-to-Ethernet connectivity using the Lantronix XPort to provide an easy-to-integrate, compact package.

XPort EDGE Tech Specs

Data Communication

• TruPort® Serial Technology — TCP and UDP Server Mode, TCP and
UDP Client Mode, Multi-host Connect; TLS Client and Server
• TruPort® Socket — Multi-host Client and Server Modes, HTTP(S)
Server
• Authenticated SMTP Support — Send email directly from device

Security and Authentication

• TruPort® Security Software
– Secure Boot, Secure Firmware-Over-the-Air (FOTA) Updates
– Secure Key Storage, Encrypted Configuration
– Secure Connections with SSL/TLS, HTTPS
– Software Controlled Network Service Ports Enable/Disable
– Role Based Access Control
– IEEE 802.1X Network Access Control (EAPOL)
• SSLv3/TLS 1.2 with PKI and X.509 Certificates (up to 2048-bit
Keys)
• TLS 1.2, AES (256-bit, 192-bit, 128-bit), up to 4096-bit RSA keys,
SHA-2

Management Interfaces

• Lantronix Percepxion™ cloud-based IoT edge solution
• Serial Port, Telnet, Internal Web Server (HTTP/HTTPS), SNMP
• Lantronix Device Discovery Protocol (L2CAP)
• Secure Firmware Upgrade via HTTP, Percepxion™

Protocol Support

• DHCP Client v4/v6, BOOTP
• Telnet Server, HTTP server
• IPv4/IPv6, TCP/IP, UDP/IP, ARP, ICMP, Auto-IP, DNS, SNMP v1/v2

Ethernet Specifications

•  IEEE 802.3 MAC and PHY, 10BaseT and 100Base-TX with HP Auto-MDIX
• Auto Negotiation; Full duplex and half duplex support
• Link Activity LED Indicators

Serial Interface Specifications

• 1x UART (Serial) Ports
• CMOS (Asynchronous) 3.3V Level Signals
• Data Rates: 9600 bps to 4Mbps (software selectable)
• Data Bits: 7 or 8; Stop Bits: 1 or 2; Parity: Odd, Even or None
• Control signals: DTR/DCD, RTS/CTS
• Flow Control: XON/XOFF (software), RTS/CTS (hardware), None

Configurable I/Os

• Programmable I/O: up to 3 CPs
• I/O Voltage: 3.3V

Architecture

• CPU: Cortex R4 up to 320 MHz
• Storage: 8MB SPI Flash; 1MB for File System

Power

• Input Voltage: 3.3VDC
• Current consumption: 160 mA (100Base-TX); 180 mA (10Base-T)”

Environmental

• Operating Temp: -40°C to +85°C
• Storage Temp: -40°C to +85°C
• Storage Humidity: 5% to 95% relative humidity, non-condensing

Dimensions

• Dimensions: 33.9 x 16.25 x 13.5 mm (1.33 x 0.64 x 0.53 in)
• Weight: 9.6g (0.34 oz)

Packaging

• Tray: 50 units/tray (200 units Carton)
• Sample: 1 unit (Box)

Developer Tools

• SDK available for download from Lantronix
• For more information, refer to:
– docs.lantronix.com/products/xport-edge/sdk

Certifications

• FCC, EU, Canada Class B emission/immunity and UL/CB 60950/62368 safety.
For other certifications, please refer to the XPort EDGE Data Sheet.

Warranty

• 2 Year Limited

Lantronix Part # Name Description Order Now
Sorry, no parts were found that match that search query.
Lantronix Part #
XPE200100B
Name
XPort EDGE

XPORT EDGE EMBEDDED ETHERNET GATEWAY, UART, RJ45 ETH, TRAY

Contact Us
Lantronix Part #
XPE200100EK
Name
XPort EDGE – Evaluation Kit

XPort EDGE – Evaluation Kit

Buy Now
Lantronix Part #
XPE200100S
Name
XPort EDGE

XPORT EDGE EMBEDDED ETHERNET GATEWAY, UART, RJ45 ETH, SAMPLE

Buy Now

Lantronix's Full Solution & Service Offering

Percepxion
The Percepxion™ IoT edge solutions platform provides comprehensive device life cycle management, application integration and data analytics,​ so you can focus on your business.
