PremierWave 2050: Enterprise Wi-Fi Module
Reliable, Industrial Grade 802.11ac Wi-Fi Connectivity
For mission critical industrial and commercial applications, PremierWave 2050 delivers reliable and always-on 5G Wi-Fi (802.11ac) connectivity. With a production ready software stack, enterprise class security and modular RF certification, PremierWave 2050 mitigates development and deployment risks and accelerates the availability of robust WLAN connected IoT products.
- Simple and Reliable Enterprise Wi-Fi Connectivity for Ethernet devices
- Industrial grade 802.11ac Wi-Fi Module for high performance Enterprise IoT
- Production ready software for mission critical operations
- Enterprise grade security
- Simultaneous AP and Client Access (AP+STA), AP Only or Client (STA) Only Modes
- Modular RF certification, Wi-Fi Alliance Certified, IPv6 Ready Logo Certified
- Remote management
Overview for PremierWave 2050
Industry’s First Industrial Grade 5G Wi-Fi Module for Ethernet Devices
Delivering reliable and always on 5G Wi-Fi® (802.11ac) connectivity, the Lantronix® PremierWave® 2050 is a series of embedded modules designed specifically for sensitive, mission critical, industrial and commercial applications. With a production ready software stack and modular RF certification, the PremierWave 2050 simplifies deployments and accelerates availability of robust WLAN connected IoT products.
Production Ready
Building and maintaining Wi-Fi connectivity software and keeping up with the pace of innovation in Wi-Fi technologies can consume significant resources in budget and time. With the PremierWave 2050, design engineers and system architects can reduce product development time and deploy their devices with confidence that their products will connect and work as expected. With optimized hardware and robust software for Wi-Fi connection management, secure system management and configuration functions, and robust Ethernet to Wi-Fi bridging the PremierWave 2050 lets you ease the deployment and support of your Wi-Fi enabled product.
Integrated Enterprise Security
Secure Wi-Fi connectivity requires supporting scalable enterprise class Wi-Fi via Extensible Authentication Protocol (EAP) methods and secure AES (CCMP) ciphers. To protect management interfaces, PremierWave 2050 uses SSL/TLS and SSH for data encryption and PKI/Certificate Management for authentication and key management. In addition, PremierWave 2050 offers firewall features to block ports and has NIST-certified AES encryption.
Designed for Industrial and Commercial Applications
Enterprise and industrial IoT applications are mission critical in nature and require robust, always-on, secure connectivity. Featuring a robust application stack and connection management, antenna diversity, 5 GHz Wi-Fi bands support, and the ability to operate in extended temperature environments, the PremierWave 2050 is ideal for delivering reliable wireless connectivity for a wide range of industrial and commercial applications.
Features & Specifications for PremierWave 2050
Wireless LAN Interface
- IEEE 802.11ac (1×1) up to 433 Mbps; IEEE 802.11n (1×1) up to 150 Mbps
- 20, 40 and 80 MHz (ac only) channel width with optional SGI
- Dual Band 2.4 GHz and 5 GHz, Channels 1-14, UNII-1, 2, 2e and 3
- Compatible with 802.11 a/b/g, Supports IEEE 802.11 d/h/i
- Transmit Beamforming, Tx/Rx Low Density Parity Check (LDPC), Rx Space Time Block
- Coding (STBC)
- Bluetooth/WLAN Coexistence
Ethernet
- IEEE 802.3 MAC and PHY, 10BaseT and 100BaseT
- Auto Negotiation/Auto MDIX, Full duplex and half duplex support
Security and Authentication
- AES/CCMP and TKIP encryption, WPA/WPA2 Personal
- WPA2 Enterprise (EAP-TLS, EAP-TTLS, EAP-PEAPv0/v1, EAP-FAST)
- SSH v1/v2, SSL v3, TLS v1, PKI, Supports up to 2048-bit RSA
- NIST Certified AES (FIPS-197)
Management Interfaces
- CLI (via Serial Port, Telnet, SSH)
- Web Browser (HTTP/HTTPS), Web Services API (HTTPS)
- XML Configuration and XML Status (CLI, FTP, API)
- OTA Field upgradeable
Protocol Support
- DHCP Client, DHCP Server, DHCPv6 Client
- uPnP (Discovery), LCAP (77FE), Telnet, SSH, (S)FTP, HTTP(S)
- IPv4/IPv6, TCP, UDP, ARP, ICMP, Auto-IP, DNS , SNMP v2/v3
Wireless Features
- Soft Access Point with DHCP Server, DNS Proxy, Wi-Fi Direct
- 14 simultaneous client connections to Soft AP interface
- Simultaneous AP and Client mode
- Connect to multiple WLAN networks, WLAN QuickConnect
- Ethernet to Wi-Fi Client Bridge (Single Host Mode), Auto-MAC ID
Power
- Input Voltage: 5 VDC
- Average Typical: 270mA
- Peak Typical: 500mA
- Boot Surge Typical: 930mA
Dimensions
- 45.66 mm (L) x 45.07 mm (W) x 3.5mm (H) +/- 0.3 mm
Packaging
- JEDEC Tray – Bulk
- MSL Level 3 Bag – Sample
Environmental
- Operating Temp: -40°C to +85°C
- Storage Temp: -40°C to +85°C
- Relative Humidity: 0% to 90% non-condensing
Certifications
- FCC, CE, Industry Canada, Japan, Mexico, China, AUS/NZS
- UL/CUL/CB
- See Data Sheet for Details
Warranty
- 5 Year Limited
Order Information & Part Numbers for PremierWave 2050
Lantronix Online Store (U.S.A., Canada, Mexico, Europe)
- Call (800) 422-7055 to speak with a Lantronix sales representative in North America.
- Lantronix Worldwide Offices – Find an office in your region.
- Find a Lantronix Partner – Lantronix products are available from a variety of leading technology vendors.
| PW205010002B | PremierWave 2050 802.11ac, JEDEC Tray (Qty 120) |
PREMIERWAVE 2050, 802.11ac EMBEDDED WI-FI IOT GATEWAY, LINUX, DUAL U.FL ANT, LGA, 256M FLASH, TRAY |
Contact Us | |
| PW205020002B | PremierWave 2050 802.11ac, JEDEC Tray (Qty 120) |
PREMIERWAVE 2050, 802.11ac EMBEDDED WI-FI IOT GATEWAY, LINUX, U.FL AND CHIP ANT, LGA, 256M FLASH, TRAY |
Contact Us | |
| PW205030002B | PremierWave 2050 802.11ac, Embedded Wi-Fi GW, Thru-Hole, U.FL |
PREMIERWAVE 2050, 802.11ac EMBEDDED WI-FI IOT GATEWAY, LINUX, DUAL U.FL ANT, THROUGH-HOLE PINS, 256M FLASH, TRAY |
Contact Us | |
| PW205010002S | PremierWave 2050 802.11ac Module Sample |
PREMIERWAVE 2050, 802.11ac EMBEDDED WI-FI IOT GATEWAY, LINUX, DUAL U.FL ANT, LGA, 256M FLASH, SINGLE |
Order Now | |
| PW205020002S | PremierWave 2050 802.11ac Module Sample |
PREMIERWAVE 2050, 802.11ac EMBEDDED WI-FI IOT GATEWAY, LINUX, U.FL AND CHIP ANT, LGA, 256M FLASH, SINGLE |
Order Now | |
| PW205010002K | PremierWave 2050 Evaluation Kit, Dual u.fl |
PREMIERWAVE 2050 EVALUATION KIT, DUAL U.FL ANT, 256M FLASH |
Order Now | |
| PW205020002K | PremierWave 2050 Evaluation Kit, Chip Ant |
PREMIERWAVE 2050 EVALUATION KIT, U.FL AND CHIP ANT, 256M FLASH |
Order Now | |
| Lantronix Part # | Name | Description | Order Now | |
|---|---|---|---|---|
