Open-Q™ 4200 Series SOM

Open-Q™ 4200 Series SIP (System in Package)

The Open-Q™ 4200 Series SOM is a cost-effective solution that delivers powerful performance, vivid graphics, dynamic camera capabilities, and a broad range of connectivity options.

Product Brief Buy Now

Overview

Designed for advanced AI vision applications, the Qualcomm Dragonwing™ QCS4290 (Android) & QRB4210 (Yocto Linux) processors utilize Qualcomm Technologies’ heterogenous compute expertise to provide an SoC with multiple specialized processing cores.

This is a Wi-Fi 5 solution with some Wi-Fi 6 features: TWT & 8SS. With security, advanced camera features, and high-speed interfaces, the Open-Q™ 4200 SIP creates the perfect computing core for a variety of edge AI video analytic applications.

Along with the companion development kit, OS and SDKs, and available accessories, it will accelerate your time to market for innovative new products requiring advanced imaging and computer vision performance in low-cost and low-power embedded situations.

Key Features

Compact SIP with Qualcomm Dragonwing™ QCS4290 (Android) & QRB4210 (Yocto Linux) processors, 8-core 2.0/1.8 GHz processor
3rd generation Qualcomm AI Engine
Vivid graphics with Qualcomm Adreno 610 GPU
Multiple high speed connectivity options
Up to 6GB LPDDR4 and 256GB eMMC
Long term support with extended life hardware and software support through 2027

Engineering Services

Lantronix leverages our unparalleled engineering expertise and product development best practices to deliver high quality, innovative products, cost-effectively, and on time.

Learn More

Applications

Intelligent surveillance camera, dash camera, body camera

Fleet management with video analytics

Warehouse and logistic robots

Rugged handheld computer

Interactive display boards

Drone

Specifications

- Chipset
  - Qualcomm Dragonwing™ QCS4290 & QRB4210 processors
- Memory
  - 2 – 6GB LPDDR4
- Storage
  - 16 – 256GB eMMC
- External Storage
  - uSD
- Wi-Fi / BT
  - 802.11 a/b/g/n/ac, Wi-Fi 6-ready 8×8 sounding & Target Wake Time (TWT), 1×1 MU-MIMO 2.4/5 GHz, WPA3, Bluetooth 5.1, and FM RDS/RBDS
- Location
  - Support with external GNSS circuitry and WGR7640. Please contact us for more details.
  - Gen 9, GPS, Glonass, BeiDou, Galileo, QZSS, and SBAS.
  - NavIC support with WGR7640
- Modem
  - None
- Display Interfaces
  - One 4-lane MIPI DSI, D-PHY 1.2 (1.5 Gbps / lane). Split link supported
  - Up to FHD+ (1080 × 2520) aspect ratio
  - OpenGL ES 3.1, Vulkan 1.1, OpenCL 2.0
- Camera Interfaces
  - 3x 4-lane MIPI CSI
  - Three cameras: 13 MP + 13 MP + 5 MP or 13 MP + 8MP + 8 MP
  - Two cameras: 25 MP + 5 MP or 21 MP + 8 MP
  - (13 MP + 13 MP) / (25 MP + 5 MP) at 30 fps, or 16 MP + 16 MP at 24 fps
- Video capabilities
  - Encode & Decode: Up to 1080p 60 fps encode / 1080p 60fps decode
  - Decode: Up to 1080p60 8-bit H.264, 1080p60 8-bit HEVC (H.265), VP9
  - Encode: Up to 1080p60 8-bit HEVC (H.265), 1080p60 8-bit H.264
- AI Capability (TOPs)
  - 1.7
- Audio
  - Qualcomm SoundWire with WCD9370, 4x DMIC
- I/O
  - USB 3.1 Type C, SDIO, UART, SPI, I2C, I3C, GPIO
- PCIe
  - None
- Battery Charger
  - Yes
- Operating Temperature
  - Extended (-25C to 85C)
- Form Factor
  - SIP (LGA)
- Dimensions
  - 36 x 36 x 2.76mm
- Software
  - Android 12, Yocto Linux (Dunfell, 5.4)
- Certification
  - FCC, RED

Resources

Product Brief

No matches were found for that search.

Open-Q™ 4200 SIP Product Brief

841 KB

View

Certificates

Don’t see the certificate you need? Contact us to explore options and timelines for new certificates.

No matches were found for that search.

RoHS and REACH Certificate – Various Embedded Compute – ENV-00347

103 KB

View

Open-Q 4210 RoHS and Reach Certificate

96 KB

View

Open-Q 4290 RoHS and Reach Certificate

93 KB

View

CERTIFICATE, FCC, OPEN-Q 4200 SIP DSS

FCC

204 KB

View

CERTIFICATE, FCC, OPEN-Q 4200 SIP DTS

FCC

208 KB

View

CERTIFICATE, FCC, OPEN-Q 4200 SIP NII

FCC

212 KB

View

CERTIFICATE, IC, OPEN-Q 4200 SIP

Industry Canada

254 KB

View

CERTIFICATE, JAPAN, OPEN-Q 4200 SIP -19

JAPAN RADIO

287 KB

View

CERTIFICATE, JAPAN, OPEN-Q 4200 SIP -19-03

JAPAN RADIO

286 KB

View

CERTIFICATION, EU, OPEN-Q 4200 SIP

304 KB

View

CERT, CE DOC, OPEN-Q 4200 SIP

DofC

271 KB

View

CERT, UKCA DOC, OPEN-Q 4200 SIP

UKCA

302 KB

View

ENVIRONMENTAL CERT, MTBF, Q4290

266 KB

View

Product Notifications

No matches were found for that search.

You must log in or create a MyLantronix account to view product change notifications.

Additional technical documentation and firmware information can be found at Tech Portal HERE

Part Numbers

Filter by type:

Open-Q 4210 Series
Part Number	Name	Description
QC-SIP-4210RB-A	Open-Q™ 4210RB-A SOM	Open-Q™ 4210RB SOM, 2GB LPDDR4, 16G eMMC, Wi-Fi, BT, Yocto Linux (Dunfell, 5.4)	Buy Now
QC-SIP-4210RB-B	Open-Q™ 4210RB-B SOM	Open-Q™ 4210RB SOM, 4GB LPDDR4, 64G eMMC, Wi-Fi, BT, Yocto Linux (Dunfell, 5.4)	Buy Now
QC-SIP-4210RB-C	Open-Q™ 4210RB-C SOM	Open-Q™ 4210RB SOM, 4GB LPDDR4, 256G eMMC, Wi-Fi, BT, Yocto Linux (Dunfell, 5.4)	Buy Now
Open-Q 4290 Series
Part Number	Name	Description
QC-SIP-4290CS-B	Open-Q™ 4290CS-B SOM	Open-Q™ 4290CS SOM, 4GB LPDDR4, 64G eMMC, Wi-Fi, BT, Android 12	Buy Now
QC-SIP-4290CS-C	Open-Q™ 4290CS-C SOM	Open-Q™ 4290CS SOM, 4GB LPDDR4, 256G eMMC, Wi-Fi, BT, Android 12	Buy Now
SOM on Interposer Boards
Part Number	Name	Description
QC-SIP-CONN-4210RB-A	Open-Q™ 4210RB-A SOM on Interposer Board	Open-Q™ 4210RB-A SOM (2GB/16GB) on Interposer Board with B2B Connectors, Yocto Linux (Dunfell, 5.4)	Contact Us
QC-SIP-CONN-4210RB-B	Open-Q™ 4210RB-B SOM on Interposer Board	Open-Q™ 4210RB-B SOM (4GB/64GB) on Interposer Board with B2B Connectors, Yocto Linux (Dunfell, 5.4)	Contact Us
QC-SIP-CONN-4210RB-C	Open-Q™ 4210RB-C SOM on Interposer Board	Open-Q™ 4210RB-C SOM (4GB/256GB) on Interposer Board with B2B Connectors, Yocto Linux (Dunfell, 5.4)	Contact Us
QC-SIP-CONN-4290CS-B	Open-Q™ 4290CS-B SOM on Interposer Board	Open-Q™ 4290CS-B SOM (4GB/64GB) on Interposer Board with B2B Connectors, Android 12	Contact Us
QC-SIP-CONN-4290CS-C	Open-Q™ 4290CS-C SOM on Interposer Board	Open-Q™ 4290CS-C SOM (4GB/256GB) on Interposer Board with B2B Connectors, Android 12	Contact Us
