xPico 250 Embedded IoT Gateway
Focus

Delivering seamless and secure Ethernet, Wi-Fi and Bluetooth connectivity, the Lantronix xPico 250 line of embedded IoT gateways allows OEMS to build and deploy their smart connected products with reduced complexity and lower risk.

xPico 250 Series Highlights

  • Dual-band Wi-Fi (802.11 a/b/g/n) and Ethernet
  • Dual-mode Bluetooth (Bluetooth and Bluetooth LE)
  • Automatic network connection management
  • Concurrent Soft AP + client mode for direct wireless service access without disrupting machine field operations
  • Enables operation as network co-processor or wireless MCU
  • Global Certification (FCC, IC, ETSI, Japan, AU/NZS, China)
  • Industrial-grade design for operation in extreme environments (-40 C to +85 C)
  • Remote updates and device management via ConsoleFlow™
  • Reference SDK module for integration with Microsoft Azure cloud computing service

xPico 250 Series is Ideal for

NDAA Compliant

xPico 250 Embedded IoT Gateway Overview

Featuring advanced enterprise security, intelligent networking, production ready software, and pre-integration with the ConsoleFlow™ platform, xPico 250 line of embedded IoT gateways enables OEMs to go to market faster with their industrial IoT solutions.

Highly Integrated Wi-Fi in a Compact Design

Dual-band Wi-Fi, antenna diversity, Enterprise Wi-Fi security and robust wireless connectivity management deliver higher performance and scalable deployment within noisy industrial and enterprise settings. The xPico 250 line of embedded IoT gateways makes it easy to deploy robust Ethernet, Wi-Fi and Bluetooth connectivity without writing complex drivers. The industry-leading compact SMT footprint of the xPico 250 family allows it to fit it into any design and operate in extreme environments.

Robust Connectivity for Reliable Data Access and Management

Simplify embedded application development and go to market faster with the xPico 250 gateway’s built-in network communications engine and flexible system integration modes. Completely offload IoT communications from your embedded microcontroller when operating as a network co-processor or use it as a wireless microcontroller with the provided SDK.

Field-tested TruPort® Serial supports transparent pass-through of hundreds of proprietary serial and standard Fieldbus protocols and TruPort® Socket enables complete control over multiple connections via TCP, UDP or TLS. Configure and control the gateway operation from the host microcontroller side using command mode or the network side with Web Service APIs and XML configuration data.

Comprehensive Device Security Framework

The xPico 250 line of embedded IoT gateways includes a comprehensive suite of built-in device security applications that offer robust and secure connections, data-at-rest protection for keys, configuration, secure boot and secure firmware-over-the-air (FOTA) updates, user role-based access control and fine-grained policy-based network service control.

Cloud-based Centralized Management Service

Scalable and secure cloud-based device management for the xPico 250 embedded IoT gateways, ConsoleFlow™ combines full operational awareness of any size deployment with over-the-network remote device management and maintenance to reduce your total cost of ownership.

Case Studies

Medical & Connected Healthcare
Lantronix xPico 250 IoT gateway chosen to help create the instrument for point-of-care use.

xPico 250 Embedded IoT Gateway Tech Specs

Network

Wireless Specifications

  • IEEE 802.11 a/b/g up to 54 Mbps; 802.11 n (1×1) up to 150 Mbps
  • 20 and 40 MHz channel width with optional SGI
  • Dual Band 2.4 GHz and 5 GHz, Channels 1-13, UNII-1, 2a, 2e and 3
  • Supports IEEE 802.11 d/h/i
  • Bluetooth/WLAN Coexistence
  • 802.11r fast roaming

Ethernet Specifications

  • IEEE 802.3 MAC, 10Base-T and 100Base-TX (RMII)

Bluetooth Specifications

  • Compliant to Bluetooth Core Specification version 4.2 (BR/EDR/Bluetooth LE)
  • Bluetooth LE Central and Peripheral Roles
  • Support for Generic Access Profile (GAP), Generic Attribute Profile (GATT), Device ID Profile
  • Serial Port Profile (SPP)

Data Communication

  • TruPort® Serial Technology— TCP and UDP Server Mode, TCP and UDP Client Mode, Multi-host Connect; TLS Client and Server
  • TruPort® Socket— Multi-host Client and Server Modes, HTTP(S), Sockets, TLS
  • Authenticated SMTP Support— Send email directly from device

Security and Authentication

  • TruPort® Security Software
    • Secure Boot, Secure Firmware-Over-the-Air (FOTA) Updates
    • Secure Key Storage, Encrypted Configuration
    • Secure Connections with SSL/TLS, HTTPS
    • Software Controlled Network Service Ports Enable/Disable
    • Role Based Access Control
  • AES/CCMP and TKIP encryption, WPA/WPA2 Personal
  • WPA2 Enterprise (EAP-TLS, EAP-TTLS, EAP-PEAP, EAP-FAST)
  • WPA3-Enterprise Transition Mode and WPA3-Personal (requires firmware v5.0.0.0 or later)
  • SSLv3/TLS 1.2 with PKI and X.509 Certificates (up to 4096-bit Keys)
  • AES Algorithm, 256-bit, 192-bit, 128-bit

Management Interfaces

  • Lantronix ConsoleFlow™ Cloud Software Platform, REST, MQTT
  • Lantronix Discovery Protocol (77FE)
  • Serial Port, Internal Web Server (HTTP/HTTPS)
  • XML Configuration and XML Status (CLI, API)
  • Secure Firmware Upgrade via HTTPS, ConsoleFlow™

Protocol Support

  • DHCP Client, Server (Soft AP), HTTP Server/Client
  • IPv4, TCP/IP, UDP/IP, ARP, ICMP, Auto-IP, DNS
  • SNMP v1/v2
  • IPv6

Wireless Features

  • Concurrent Soft AP + STA (Client), Client, Soft AP
  • Up to 5 simultaneous client connections to Soft AP interface
    • Up to 4 in Concurrent Mode
  • Connect to multiple WLAN networks, WLAN QuickConnect
  • Ethernet to Wi-Fi Client Bridge (Single Host Mode), Auto-MAC ID

Power

  • Input Voltage: 3.3VDC
  • Max Current Consumption (Boot Peak): 600 mA (xPico 250)

Operating Conditions

  • Operating Temp: -40°C to +85°C; Storage Temp: -40°C to +100°C
  • Vibration (Operational): 40G; Non-operational Shock: 65G
  • Storage Humidity: 5% to 85% relative humidity, non-condensing

Host Interfaces

  • Serial: UART Port TTL
    • Data Rates: 9600 bps to 4 Mbps (software selectable)
    • Control signals: DTR/DCD; Flow Control: RTS/CTS; XON/XOFF
  • USB (Host), 12 Programmable I/O Pins (GPIOs)
  • System Pins: RESET, DEFAULT, WAKE

Dimensions & Packaging

  • Dimensions: 17mm x 25mm x 2mm (LGA); 22mm x 35.5mm x 2.73 mm (Edge Card)
  • For LGA: Tape and Reel, MSL 3
  • For Edge Connector: Tray

Certifications & Compliance

  • Type Approvals: USA (FCC Part 15), Canada (IC RSS), EU (RED), Japan (MIC), China (SRRC), AU/NZS
  • Safety: IEC 62368 EN 62368, EN 62311, UL 60950
  • RoHS, REACH

Warranty

  • 5-Year Limited

Related Products

  • XPC250300EK – xPico 250 Embedded Gateway, Evaluation Kit, Wi-Fi, Bluetooth + Ethernet

xPico 250 Embedded IoT Gateway Downloads

Additional Product Information
Firmware Downloads

Keep your products up to date by downloading the latest firmware. You must log in or create a MyLantronix account to download firmware.

Product Notifications

You must log in or create a MyLantronix account to view product change notifications.

Lantronix Part # Name Description Order Now
Sorry, no parts were found that match that search query.
SKU
Lantronix Part #
XPC250100S-02
Name
xPico 250

XPICO 250 Embedded IOT GW, 802.11 A/B/G/N, ETH, Bluetooth 4.2, Dual u.fl, Ind. Temp, LGA T&R 25

Buy Now
Lantronix Part #
XPC250300S-02
Name
xPico 250

XPICO 250 Embedded IOT GW, 802.11 A/B/G/N, ETH, Bluetooth 4.2, Dual u.fl, Ind. Temp, Edge Conn, Single

Buy Now
Lantronix Part #
XPC250100B-02
Name
xPico 250

XPICO 250 Embedded IOT GW, 802.11 A/B/G/N, ETH, Bluetooth 4.2, Dual u.fl, Ind. Temp, LGA, T&R 250

Contact Us
Lantronix Part #
XPC250300B-02
Name
xPico 250

XPICO 250 Embedded IOT GW, 802.11 A/B/G/N, ETH, Bluetooth 4.2, Dual u.fl, Ind. Temp, Edge Conn, Tray

Contact Us
Accessories
Lantronix Part #
500-180-R-ACC
Name
Cable

ACCESSORY, CABLE, ANTENNA, U.FL to R-SMA, 152.40 mm Length, 10-pc Bulk Pack.

Buy Now
Lantronix Part #
500-181-R-ACC
Name
Cable

ACCESSORY, CABLE, ANTENNA, U.FL to U.FL, 152.40 mm Length, 10-pc Bulk Pack.

Buy Now
Lantronix Part #
500-182-R-ACC
Name
Cable

ACCESSORY, CABLE, ANTENNA, U.FL to R-SMA, 38.10 mm Length, 10-pc Bulk Pack.

Buy Now
Lantronix Part #
ACC-500-0378-00
Name
Cable

ACCESSORY, CABLE, ANTENNA, U.FL to U.FL, 254 mm Length (10 inch)

Buy Now
Lantronix Part #
ACC-500-0390-00
Name
Cable

ACCESSORY, CABLE, ANTENNA, U.FL to R-SMA, 254mm Length (10 inch).

Contact Us
Lantronix Part #
ACC-930-033-R
Name
Antenna

ACCESSORY, ANTENNA, 2.4 GHZ and 5GHZ, 2.15 dBi, RP-SMA, ROHS

Contact Us
Lantronix Part #
XPW100A003-01-B
Name
Antenna

ACCESSORY, ANTENNA, U.FL to PCB Strip (50 mm cable), 2.5dBi 2.39 GHz to 2.49 GHz, 5 dBi 4.9 GHz to 5.9GHz, 50-pc Bulk

Contact Us
Compatible Accessories
Lantronix Part #
XPC240300EK
Name
xPico 240 Evaluation Kit
xPico 240 Evaluation Kit, Embedded IoT GW, Dual-band Wi-Fi, Eth Buy Now
Lantronix Part #
XPC250300EK
Name
xPico 250 Evaluation Kit
xPico 250, Evaluation Kit, Embedded IoT GW, Dual-band Wi-Fi, Eth, Bluetooth 4.2 Buy Now
Lantronix Part #
XPC270300EK
Name
xPico 270 Evaluation Kit
xPico 270 Embedded IoT Gateway, Evaluation Kit, Wi-Fi, Bluetooth 4.2 + Ethernet Buy Now
