Open-Q™ 9075IQ SOM (System on Module)

New

Processor

• Qualcomm® IQ-9075 SoC built on 5nm LPE process..

  • Kryo™ Octa-core CPU: 1 Prime @ 3.36 GHz + 3 Gold @ 2.8 GHz + 2 Silver @ 2.0 GHz
  • Quad Kryo Gold Prime with 512 KB L2 cache per core, targeting up to 2.36 GHz
  • 2 MB shared L3 cache per cluster
• Adreno™ 663 GPU
• Spectra™ Image signal processor 690
• Adreno™ 765 Video processing unit
• Adreno™ 1199 Display processing unit

• Dual Hexagon Tensor Processor (integrated with Hexagon DSP, quad Hexagon Vector eXtensions, and dual Hexagon Matrix eXtensions co-processors), two general-purpose DSPs and one audio DSP Safety Island (SAIL) subsystem (9100IQ) or Real-time subsystem (9075IQ)

Memory/Storage

• 36GB LPDDR5 up to @ 3200MHz, two UFS 3.1 gear 4, 2-lane interfaces, NVMe via PCIe
• NOR flash memory as SAIL domain boot up device

Wireless

• Support Wi-Fi 6 802.11ax 2×2 MU-MIMO with external PCIe module

Display Interfaces

• 2x 4-lane MIPI DSI with VESA DSC v1.2, D-PHY v1.2 up to 20 Gbps total, or C-PHY v1.1 up to 34 Gbps total
• 4x eDP/DisplayPort v1.4 at 8.1 Gbps/lane, 32.4 Gbps/port, MST, and VESA DSC v1.2a and forward error correction
• Up to maximum of 48MP, example configuration is up to 5x 4K display

Camera Interfaces

• 4x MIPI CSI D-PHY 1.2 or C-PHY 2.0 camera ports with eight dedicated CCI I2C
• Up to 16 concurrent cameras, 2 IFE + 5 IFE Lite

Video Performance

• Video decode up to UHD275. Native decode support for AV1, HEVC, H.264, H.265, VP9, and MPEG-2 codecs
• Video encode up to UHD170. Native encode support for HEVC, H.264, and H.265
• Concurrent UHD120 decode and UHD60 encode, or UHD60 decode and UHD120 encode

Audio

• Support LS-I2S interfaces, PCM/TDM interfaces, and High-speed I2S interfaces

High Speed Connectivity

• 1x PCIe Gen4 2-lane, 1x PCIe Gen4 4-lane
• 2x USB 3.1 Gen 2 (HS + SS, support device and host modes)
• 1x USB 2.0 (HS, support device and host modes)
• 1x SAIL domain RGMII interface with MDIO for Ethernet with AVB
• 8x CAN-FD interfaces located in SAIL domain

• 2x SGMII interfaces supporting up to 2.5 Gbps each

Operating Environment

• Input voltage: 3.3V Typical
• Operating Temperature: -40 to +115°C Junction temperature

Power/Battery

• Power management

Form Factor

• 65 x 65 x 4.55 mm LGA SOM

Software

• Qualcomm® Linux

I/O Interfaces

• Qualcomm Universal Peripheral (QUP), UART, I2C, SPI master, SPI slave, QSPI, GPIO ports, and SAIL domain GPIO ports
