M100 485 Series
Discontinued

This compact and intelligent modem running Open AT® Application Framework, supports specific protocols and accessories specifically developed by Lantronix to ease integration with industrial equipment such as electricity meters, programmable logic controllers, lifts and vending machines.

M100 485 Series Overview

The M100 485 is the perfect solution for M2M applications facing tough environmental conditions and extended lifetime requirements. This compact and intelligent modem running Open AT® Application Framework supports specific protocols and accessories specifically developed by Lantronix to ease integration with industrial equipment such as electricity meters, programmable logic controllers, lifts and alarm systems. The M100 485 is fully type approved in CDMA or 3G and ready for global deployment.



Dual or tri-band HSDPA

The M100 485 Series is ready for global deployment and supports a large range on network frequencies (dual or tri-band) with High Speed Downlink Packet Access (HSDPA). This technology offers you high speed downloads for your installations, up to 3.6 Mbit/s.



Half-duplex RS-485

RS-485 allows multiple devices (up to 32) to communicate at half-duplex on a single pair of wires, plus a ground wire, at distances up to 4000 feet. The length of the network and the number of nodes can easily be extended thanks to various repeater products actually sold on the market for low prices.

Digital input / output x 2

The M100 485 Series features two digital I/Os’ port which could be used for alarm, tampering detection or to trigger an event.



GPS One™

Using a combination of GPS satellite signals and the cell towers themselves, gpsOne allows your location to be plotted with greater accuracy than traditional GPS systems in areas where satellite reception is problematic due to buildings or environment and tell 911 dispatchers where your device is located is case of emergency with more accuracy.

USB 2.0

The M100 485 Series modems includes a mini-USB port for direct connection to a computer or industrial equipment.







M100 485 Series Tech Specs

M100 485 Series common features

  • Half-duplex RS-485
  • Modbus RTU master
  • Modbus RTU to TCP gateway
  • USB 2.0
  • Data-logging with export to FTP

M100 CDMA 485

  • Verizon Wireless CDMA2000 1X:
  • Digital input x 2
  • gpsOne™

M100 3G 485

  • Dual or tri-band HSDPA:
  • Digital input / output x 2
  • gpsOne™
